Small pellets burner
Characteristic:
1. It burns wood pellets with diameter 6-8mm.It ensures an efficient andlow-emission combustion.
2. OKK Produced of high-grade stainless steel,it withstands temperatures up to 1200.The built-in CPU-controlled unit, automatic, cleaning system and internal auger manager the burner operation for optimum efficiency.
3. STB thermostat (option)
Technical Parameters:
name
model
HF-3
HF-5
HF-10
HF-15
Power
range(KW)
10-35
20-50
50-100
80-130
Calorific
value(KCAL)
30000
50000
100000
130000
Combustion fan
45W
65W
90W
120W
220v/50-60HZ
220v/50-60HZ
220v/50-60HZ
220v/50-60HZ
Burner
160mm
160mm
200mm
200mm
Burner
furance
High temperature resistant stainless steel pipe
Burner cover
Galvanized sheet
Igniter
600W/220V/50HZ
Storage Size
400*400*700MM
550*550*800MM
Wooden
pellets
Length:6-8mm
length:10-30mm
Capacity (kg)
50
50
100
100
Burner rate
above>=95%
Energy
consumption
2-8KG/H
3-10KG/H
6-20KG/H
10-32KG/H
Heating area
180-350M2
350-500M2
500-800M2
900-1200M2
Feeding power
220W/0.52A/220V/50-60Hz
Control Mode
Control unit
Dimensions(mm)
320*300*550
330*300*550
350*320*580
380*350*650
Burner weight
23kg
24kg
27kg
30kg
The above parameters for technical improvement,if there is a
change in the factory actual shall prevail.
